Main features :
Equipped with multiple cutting units for simultaneous cutting on all four sides
A mobile optical sensor reads the most diverse cutting marks for the accurate cutting
Manual alignment of the prints to be cut in the longitudinal direction, while the vertical cutting units are set manually
Speed 500 linear meter/hr
Available for most varied materials, including photo papers, vinyl, paper for inkjet printing, polyester or polycarbonate films up to a thickness of 0.5 mm
Easy loading of the reels
Electronic controls with visual displays allow the operator to easily check any errors or malfunctions
Vertical self-sharpening Blade
Horizontal self-sharpening Blade
Optionals :
Laser
Single vertical blade
Double vertical balde
Online kit (this optional allow to put the machine online with almost all the printer)
Datasheet	Generals
Max. operating width	1650 mm
Dimensions	165 > 2160x800x1110 mm; 165 Kit on line > 1650x1940x350 mm
Weight	165 > 95 kg; 165 Kit on line > 36 kg
Consumption	0,5 A
Datasheet	Horizontal cut	Vertical cut
Max thickness	1 mm	0.5 mm
Speed	40 m/min (131,24 ft/min.)	12,5 m/min (41,01 ft/min.)
Tolerance	± 1mm. to the mt	/
The manufacturers reserves the right to change technical and aesthetical specifications without notice.
Datasheet	Reel
Max. diameter of roll	Ø 300 mm
Max. width of roll	1650 mm
Max. weight of roll	60 kg
