Professional multisystem modular binding equipment.
Electric, foot drive, good efficiency – up to 25 sheets of paper (80 gr./m²).
Available 9 interchangeable punching modules.
It takes up little space and can replace existing traditional punching equipment for wire and plastic binding.
Operation type : electric.
Metal housing : Yes.
Adjustable backgauge : Yes.
Dimensions : W=436mm x d=219mm x H=401mm.
Weight : 30kg.
Warranty 1 year.

Pas de traduction en anglais.

Electric punch high yields interchangeable tools.
Use tools Wire-o 3.1 (34 holes) and 2.1 (23 holes), and the perforation holes 21 for plastic spiral.
Change tools in less than 1 minute.
Punching capacity: 35 sheets 80g.
Drilling speed: up to 20,000 sheets / hour.
All punches are releasable for punching out standard formats.
Warranty 1 year.

The SP-360E Electric Perforator is a mixed solution intended for copy-services and administrations needing a high-performance device.
Automatic paper ejection after electric vertical punching 35-40 sheets.
Supplied without punching tools to choose from as options.
Choice of the type of perforation interchangeable tools: Plastic & Metal Rings Pitch 3:1 & Pitch 2:1, Coil Pitch 4:1.
Adjustable perforation depth : Yes.
Maximum document length : 360mm.
Perforation speed : up to 28,000 sheets / hour.
Perforation capacity : 25 sheets 80gr./m².
Machine weight : 35kg.
Machine dimensions : W=985mm x D=744mm x H=300mm.
Electrical connection 220-240V - 50HZ.
Electric power : 2000w.
Complies with CE safety standards.
1 year warranty.

Meet the all-new GBC® Magnapunch™ Pro. This powerful interchangeable die punch is the fastest in the industry and delivers unparalleled reliability and durability.
Boasting a half-second punch cycle, the Magnapunch Pro provides your office or print shop with a best-in-class high-volume desktop punch.
Half-second punch cycle.
Efficient power system driven by flywheel technology that converts electric energy to kinetic energy, allowing for faster acceleration and punching.
Punches up to 49 sheets at a time (varies by punch pattern).
Punch activated by table top trigger or foot pedal to maximize throughput.
Easily accessible punch-pins.
Large chip tray with capacity for chips from 40,000 sheets.
All-metal housing.
Redesigned metal cover with die set ruler viewer.
Cast aluminum base that acts as a durable platform for the punching mechanism.
Durable precision worm gears constructed from high-grade carbonized steel, which allow for quick energy transfer and faster punching.
Enhanced edge guide with adjustable sliding knob and screw system.
Locking die set system with integrated safety switch, 13 die sets (including a new wire calendar die), and compatibility with Magnapunch 2.0 dies.

Electric punch table high performance.
Punching capacity approx. 1800 - 2000 cycles per hour.
Punching width 340 mm max.
Automatic or manual mode choice (footswitch).
Quick and easy tool change (2 min. Max.) Through retractable paper conveyor.
Vertical easy installation paper.
Paper guide to semi-automatic adjustment.
Receiver removable paper for non perforated paper.
Box of variable reception with a front drawer for perforated paper.
Automatic drain throat punch at a club Walking.
Punches punching tools can be disengaged by a
The distance to edge tools is adjustable.
Gear dog.
Special equipment:
Round shot thumb, 20mm, only for full binding, 3:1 pitch.
Warranty 1 year.

Electric punch RENZ Punch 500 with a universal vocation of perforating tools interchangeable.
Working width 500mm.
Cycles of theoretical perforation: 3000 - 3500/h.
Punching capacity in practice: 400-500/h.
Maximum thickness perforation: 2.5 -3.0mm.
QSA advantageous tools (punch knives disengageable by a)
Ultra-fast exchange of punching tools.
Perforating tools into two parts with boost.
Warranty 1 year.

Very robust machines designed for continuous operation, equipped with a new training technique, used to perforate paper, cardboard and plastics up to 70cm working width.
Easy handling through footswitch or sitting or standing.
The vertical paper ensures easy handling and friendly particularly large formats.
Further, grooving is also possible to place any of the sheet.
The side openings allow the perforation of double length formats.
The great advantage of Punchers Super 700, besides their ability to particularly high perforation is the possibility to use
almost all drilling tools or other brands, using adapters.
They therefore allow universal use.
Tool change easy and fast in minutes.
Their sophisticated technique that has been proven for years guaranteed them a long life.
With interchangeable tools, it is possible to work such as grooving, perforating and cutting directories.
Working width 700mm.
For medium and large print runs, especially in the production of calendars.
Format of the perforated page : max. 700mm.
Format of the imperforate page min. 60mm.
Punching thickness : max. 4.5 mm (depending on the tool).
Drilling speed : 400 - 500 rounds / h (depending on the operator).
Laying the paper : horizontal.
Weight : 40 to 1000 gr./m².
Cutting directory : yes.
Interchangeable tools : yes.
Tool change in a few minutes.
Format change: in minutes thanks to QSA tools.
Edge distance adjustable sheet yes.
Perforating punches detachable yes.
Dimensions: Length x Width x Height: 900 x 850 x 1100mm.
Warranty 1 year.

Perforateur entièrement automatique, compact et productif, idéal pour vos moyens et importants tirages de perforation.
Système d'alimentation automatique permettant de traiter sans aucun problème des liasses de documents mixés issus d'impressions offsets et numériques.
Moteur puissant et silencieux de 900w permettant la perforation de liasses jusqu'à 1,2mm d'épaisseur.
Table d'alimentation haute pile, automatiquement ajustée en hauteur.
Table de réception haute pile inclinée pour un taquage parfait des documents perforés.
Ecran LCD tactile pour une utilisation aisée.
Grand réceptacle à confettis amovible.
Machine compacte, montée sur roulette.
Principales caractéristiques techniques :
Cycles d'actionnement mécanique : 3.600/heure.
Largeur min. de perforation : 148mm.
Largeur max. de perforation : 320mm.
Long. min. du bord non perforé : 148mm.
Long. max. du bord non perforé : 300mm.
Épaisseur max. de perforation : 1.2mm.
Perforation Automatique.
Matrices de perforation proposées : Pas 3:1 wire-O, Pas 2:1 wire -O, coil, reliure plastique, etc...
Poinçons débrayables (QSA).
Temps de changement de matrice : 1,5 minute.
Dimensions de la machine : L=1.420 x l=812 x H=1.326mm.
Poids de la machine : 380kg.
Alimentation électrique : 230V~50Hz / 0.9kW.
Conforme aux normes de sécurité CE.
Garantie 1 an.

Far 5/55 has been developed for fast punching of loose sheets in large quantities with any size and type of holes required for the different binding systems: wires, spiral, plastic combs.
The Far 5/55 machine has been designed and manufactured with the utmost care in order to achieve top standard reliability and a long working life.
Change over of the tools is very fast and safe.
How does it works :
Far 5/55 can be fed continuously with material of variable thickness (paper and/or light cardboard).
Sheets are safely picked-up by an apposite device in bunches of 1,5 to 2mm each time, centred and then punched with precision and accuracy.
The sheets are solidly shift by four transport belts into the punching area where they are registered by a special device and then punched. Punched materials are preserved in numerical sequence and collected on a conveyor separately driven, in shingle style, so that the further procedure in made easier.
Features :
Maximum thickness per stroke : 2,5mm (standard 1,5 mm).
Maximum punching size : 550mm x 550mm.
Minimum punching size : 160mm (on punching side) x 120mm.
Speed : adjustable up to 120 strokes/minute.
Punching distance from the edge : adjustable up to 40mm.
Wide range of punching tools available, including tool for plastic-coils holes.
Technical Spécifications :
Power Supply : 240V single phase 50/60Hz.
Power Drive : 3Kw.
Dimensions machine : W=3200mm x D=760mm x H=1200mm.
Weight: 1250Kg.
Standard Punching Tools :
GF-55/3G: 3:1” pitch, three 3,7 x 4,0mm hole/inc., 550mm punching length, including thumb cut for hanger application.
GF-55/3: 3:1” pitch, three 3,7 x 4,0mm hole/inc., 550mm punching length. Suitable when using 5/16”, 3/8” and 7/16” wires.
GF-55/2: 2:1” pitch, two 4,7 x 5, mm. hole/inc., 550mm. punching length. Suitable when using 5/8” and 3/4″ wires.
Any other shape of punching bars may be supplied on request.
Warranty 1 year.

Each Renz machine is the result of numerous technical innovations and considerable practical experience.
The AP-360 Digital meets a variety of requirements, which were established as the result of an intensive exchange of ideas with users.
The result is top quality punching technology delivering totally new levels of performance and economic efficiency.
Control system AP-360 Digital :
Format adjustment without tools using servo motors ensures the quickest possible set up times. The machine settings are entered on the screen and can be saved in memory for repeated use.

Improved profits :
Punching can be a bottleneck in the production chain whether you produce small and average sized runs or extremely large runs. Efficient production of these jobs is the key to added profits.
The AP-360 Digital gives you the shortest set up times and allows you to punch small quantities efficiently.
In addition, the AP-360 is mounted on wheels for easy transport and the compact profile can pass through standard doorways.
Two finger pick up system :
Not available in other machines in this category. The layers of paper are picked up gently, even when punching mixed paper types and heavy weight papers. An adjustable air blower is available (optional).
Turn-over drum :
After punching, the sheets are rotated around a large drum to maintain the correct page sequence at the output station.
Punching unit with QSA* dies :
Paper format can be changed in seconds with QSA* punching dies.
This feature reduces the set up time by as much as 15 minutes and is unique for fully automatic punching machines (*QSA = Quick Size Adjustment).
Drive system :
Heavy duty components and the latest stepper motor technology are used for reliable operation with minimal wear and a long life span.
Warranty 1 year.
